Akai AT-2200 FM / AM Tuner

  • € 0.00

Vintage Akai AT-2200 FM / AM tuner in the silver finish (1976 - 1979). The Akai AT-2200 tuner features a beautiful illuminated tuner scale.

Add to Wish List

Compare this Product

Specifications Akai AT-2200 tuner:
- Type: Mono/Stereo Tuner
- Tuning Bands: FM, AM
- Tuning Scale: Analogue
- FM Tuning Range: 88 to 108 MHz
- AM Tuning Range: 520 to 1605 kHz
- Sensitivity: 1.9uV (FM), 180uV (AM)
- Signal to Noise Ratio: 70dB (FM), 45dB (AM)
- Distortion: 0.5% (FM)
- Selectivity: 60dB (FM), 30dB (AM)
- Output: 1000mV (FM), 350mV (AM)
- Semiconductors: transistors x 5, diodes x 7, Fets x 1, ICs x 3
- Dimensions (W x H x D): 380 x 125 x 263 mm
- Weight: 4.2 kg

Product:
Vintage Akai AT-2200 FM / AM tuner in the silver finish (1976 - 1979).

The Akai AT-2200 tuner features a beautiful illuminated tuner scale.

Condition:
Technical condition: 10 / 10
Cosmetic condition: 8 / 10

Electric power requirements:
Input voltage: 220 V
Input frequency: 50 Hz
